配件信息 |
|
|
|
FC號 |
PN號 |
描述 |
|
CPU |
|
|
|
|
438090-B21 |
HP DL580 G5 Intel® Xeon® E7340 (2.40GHz/4-core/8MB/80W) Processor Kit |
|
|
438091-B21 |
HP DL580 G5 Intel® Xeon® E7330 (2.40GHz/4-core/6MB/80W) Processor Kit |
|
|
438092-B21 |
HP DL580 G5 Intel® Xeon® E7320 (2.13GHz/4-core/4MB/80W) Processor Kit |
|
|
438093-B21 |
HP DL580 G5 Intel® Xeon® E7310 (1.60GHz/4-core/4MB/80W) Processor Kit |
|
|
438100-B21 |
HP DL580 G5 Intel® Xeon® L7345 (1.86GHz/4-core/8MB/50W) Processor Kit |
|
|
438101-B21 |
HP DL580 G5 Intel® Xeon® E7220 (2.93GHz/2-core/8MB/80W) Processor Kit |
|
|
451999-B21 |
HP DL580 G5 Intel® Xeon® X7350 (2.93GHz/4-core/8MB/130W) Processor Kit |
|
|
487373-B21 |
HP DL580 G5 Intel® Xeon® X7460 (2.67GHz/6-core/16MB/130W) Processor Kit |
|
|
487373-L21 |
Intel® Xeon® X7460 2.67GHz Hexa Core 16MB DL580 G5 Factory Integrated Processor Option Kit |
|
|
487375-B21 |
HP DL580 G5 Intel® Xeon® E7450 (2.40GHz/6-core/12MB/90W) Processor Kit |
|
|
487375-L21 |
Intel® Xeon® E7450 2.4GHz Hexa Core 12MB DL580 G5 Factory Integrated Processor Option Kit |
|
|
487377-B21 |
HP DL580 G5 Intel® Xeon® E7440 (2.40GHz/4-core/16MB/90W) Processor Kit |
|
|
487377-L21 |
Intel® Xeon® E7440 2.4GHz Quad Core 16MB DL580 G5 Factory Integrated Processor Option Kit |
|
|
487378-B21 |
HP DL580 G5 Intel® Xeon® E7430 (2.13GHz/4-core/12MB/90W) Processor Kit |
|
|
487378-L21 |
Intel® Xeon® E7430 2.13GHz Quad Core 12MB DL580 G5 Factory Integrated Processor Option Kit |
|
|
487380-B21 |
HP DL580 G5 Intel® Xeon® E7420 (2.13GHz/4-core/8MB/90W) Processor Kit |
|
|
487380-L21 |
Intel® Xeon® E7420 2.13GHz Quad Core 8MB DL580 G5 Factory Integrated Processor Option Kit |
|
|
506157-B21 |
HP DL580 G5 Intel® Xeon® L7445 (2.13GHz/6-core/12MB/50W) Processor Kit |
|
|
506157-L21 |
HIntel® Xeon® L7445 2.13GHz Six Core 12MB DL580 G5 Factory Integrated Processor Option Kit |
|
系統板 |
|
|
|
|
449415-001 |
Hp Processor and memory module tray assembly, SPS-BD CPU DL580G5 |
|
|
449417-001 |
HP DL580G5 SPI Board |
|
|
452179-B21 |
DL580 G5 Memory expansion boards option |
|
內存 |
|
|
|
|
351580-B21 |
128MB BBWC for SA641/642 |
|
|
397411-B21 |
2 GB FBD PC2-5300 2 x 1 GB Dual Rank Kit |
|
|
397413-B21 |
4 GB FBD PC2-5300 2 x 2 GB Dual Rank Kit |
|
|
397415-B21 |
8 GB FBD PC2-5300 2 x 4 GB Dual Rank Kit |
|
|
405139-B21 |
HP Smart Array P400 256MB Cache FIO |
|
|
405148-B21 |
512 MB Battery-backed write cache upgrade |
|
|
413015-B21 |
16 GB FBD PC2-5300 2 x 8 GB Dual Rank Kit |
|
|
461826-B21 |
2 GB FBD PC2-5300 2 x 1 GB Low Power Single Rank Kit |
|
|
461828-B21 |
4 GB FBD PC2-5300 2 x 2 GB Low Power Dual Rank Kit |
|
|
462967-B21 |
HP 512MB P-Series Battery Backed Write Cache Upgrade |
|
|
462968-B21 |
HP 256MB P-series Cache Upgrade |
|
|
466440-B21 |
8 GB FBD PC2-5300 2 x 4 GB Low Power Dual Rank Kit |
|
|
495604-B21 |
64 GB FBD PC2-5300 8 x 8 GB Dual Rank Kit |
|
|
534562-B21 |
HP 1GB Flash Backed Cache |
|
|
534916-B21 |
HP 512MB Flash Backed Write Cache |
|
硬盤 |
|
|
|
|
418399-001 |
146.0GB hot-swap dual-port Serial Attached SCSI (SAS) hard drive - 10,000 RPM, 2.5-inch Small Form Factor (Option 418367-B21) |
|
|
458924-B21 |
HP 120GB 1.5G SATA 5.4K rpm SFF (2.5-inch) Entry 1 year Warranty Hard Drive |
|
|
460355-B21 |
HP 250GB 3G SATA 5.4K rpm SFF (2.5-inch) Entry 1 year Warranty Hard Drive |
|
|
507125-B21 |
HP 146GB 6G SAS 10K SFF (2.5-inch) Dual Port Enterprise 3 year Warranty Hard Drive |
|
|
507127-B21 |
HP 300GB 6G SAS 10K SFF (2.5-inch) Dual Port Enterprise 3 years Warranty Hard Drive |
|
|
507610-B21 |
HP 500GB 6G SAS 7.2K rpm SFF (2.5inch) Midline 1 year Warranty Hard Drive |
|
|
507750-B21 |
HP 500GB 3G SATA 7.2K rpm SFF (2.5-inch) Midline 1 year Warranty Hard Drive |
|
|
512545-B21 |
HP 72GB 6G SAS 15K rpm SFF (2.5-inch) Dual Port Enterprise Hard Drive |
|
|
512547-B21 |
HP 146GB 6G SAS 15K rpm SFF (2.5-inch) Dual Port Enterprise Hard Drive |
|
|
530888-B21 |
HP 160GB 3G SATA 7.2K rpm SFF (2.5-inch) Midline 1 year Warranty Hard Drive |
|
|
572071-B21 |
HP 60GB 3G SATA SFF (2.5-inch) Midline 1yr Warranty Solid State Drive |
|
|
572073-B21 |
HP 120GB 3G SATA SFF (2.5-inch) Midline 1yr Warranty Solid State Drive |
|
RAID卡 |
|
|
|
|
347786-B21 |
HP 8 Internal Port SAS 64/133 PCI-X RAID Host Bus Adapter |
|
SCSI卡 |
|
|
|
AH627A |
|
HP U320e SCSI Dual Channel Host Bus Adapter |
|
網卡 |
|
|
|
|
435508-B21 |
HP NC364T PCI Express Quad Port Gigabit Server Adapter |
|
|
458492-B21 |
HP NC382T PCI Express Dual Port Multifunction Gigabit Server Adapter |
|
|
468332-B21 |
HP NC522SFP Dual Port 10GbE Gigabit Server Adapter |
|
|
503746-B21 |
HP NC112T PCI Express Gigabit Server Adapter |
|
適配卡 |
|
|
|
|
394791-B21 |
HP NC373T PCI Express Multifunction Gigabit Server Adapter |
|
|
394793-B21 |
HP NC373F PCI Express Multifunction Gigabit Server Adapter |
|
|
412648-B21 |
HP NC360T PCI Express Dual Port Gigabit Server Adapter |
|
|
412911-B21 |
HP SC11Xe Host Bus Adapter |
|
|
416096-B21 |
HP SC44Ge Host Bus Adapter |
|
|
448397-B21 |
HP IB 4X DDR PCI-e Dual Port HCA |
|
|
452181-B21 |
PCI Express x8 3-slot option card |
|
|
452182-B21 |
PCI-X 3-slot option card |
|
|
468406-B21 |
HP 24 Bay 3Gb SAS Expander Card |
|
|
483513-B21 |
HP IB 4X DDR PCI-e Dual Port 0 Memory HCA |
|
|
488765-B21 |
HP SC08Ge Host Bus Adapter |
|
|
572531-B21 |
HP Smart Array P411/1G FBWC 2-ports Ext PCIe x8 SAS Controller |
|
|
572532-B21 |
HP Smart Array P410/1G FBWC 2-ports Int PCIe x8 SAS Controller |
|
|
578229-B21 |
HP Smart Array P411/512 FBWC 2-ports Ext PCIe x8 SAS Controller |
|
|
578230-B21 |
HP Smart Array P410/512 FBWC 2-ports Int PCIe x8 SAS Controller |
|
|
AW520A |
HP StorageWorks CN1000E Dual Port Converged Network Adapter |
|
光纖卡 |
|
|
|
|
A8002A |
HP StorageWorks FC2142SR PCI Express 4Gb Host Bus Adapter |
|
|
A8003A |
HP StorageWorks FC2242SR Dual Channel 4 Gb PCI-e Host Bus Adapter |
|
|
AE311A |
HP StorageWorks FC1142 4Gb PCI-Express Host Bus Adapter |
|
|
AE312A |
HP StorageWorks FC1242SR 4Gb PCIe dual-channel Host Bus Adapter |
|
|
AJ763A |
HP StorageWorks 82E 8Gb Dual-port PCI Express Fiber Channel Host Bus Adapter |
|
|
AJ764A |
HP StorageWorks 82Q 8Gb Dual Port PCIe Fiber Channel Host Bus Adapter |
|
|
AK344A |
HP StorageWorks 81Q PCIe Fiber Channel Host Bus Adapter |
|
|
AP767A |
HP StorageWorks 41B PCI Express 4Gb Host Bus Adapter - Single port, fiber channel |
|
|
AP768A |
HP StorageWorks 42B PCI Express 4Gb Host Bus Adapter - Dual port, fiber channel |
|
|
AP769A |
HP StorageWorks PCI Express 8Gb Host Bus Adapter - Single port, fiber channel |
|
|
AP770A |
HP StorageWorks PCI Express 8Gb Host Bus Adapter - Dual port, fiber channel |
|
電源 |
|
|
|
|
437572-B21 |
High Efficiency HP 1200W 12V Hot Plug AC Power Supply |
|
|
437573-B21 |
HP 1200W Common Slot -48VDC Hot Plug Power Supply Kit |
|
|
441830-001 |
Power supply (1200W) - Hot plug, 1U, 12V DC output |
|
|
AF452A |
HP R/T3000 UPS, Low voltage NA/JPN |
|
|
AF453A |
HP R/T3000 UPS, High voltage, NA/JPN |
|
|
AF914A |
HP 4.9kVA 24A Single Input Single Phase Monitored Power Distribution Unit |
|
|
AF916A |
HP 17.3 kVA S348 Monitored PDU- single input, 3-phase, 60A |
|
電池 |
|
|
|
|
383280-B21 |
HP Smart Array Cache Battery Kit - For Smart Array P400 Controller only |
|
光驅 |
|
|
|
|
264007-B21 |
Slimline DVD-ROM Drive (8X/24X) Option Kit |
|
|
383975-B21 |
HP DVD+R/RW 8X Slim |
|
|
481041-B21 |
HP Slim SATA DVD-ROM Optical Drive |
|
|
481043-B21 |
HP Slim SATA DVDRW Optical Drive |
|
磁帶機 |
|
|
|
|
AH558A |
HP StorageWorks 1/8 G2 Ultrium 920 SAS Tape Autoloader |
|
|
AH559A |
HP StorageWorks MSL2024 1 LTO-3 Ultrium 920 SAS Drive Library |
|
|
AH560A |
HP StorageWorks MSL4048 1 LTO-3 Ultrium 920 SAS Drive Library |
|
|
AJ823A |
DAT 320 USB External Tape Drive |
|
|
AJ825A |
HP StorageWorks DAT 320 USB Internal Tape Drive |
|
|
AJ828A |
DAT 320 WW SAS External Tape Drive |
|
|
AJ830A |
HP DAT 320 SAS Internal Tape Drive |
|
|
AK377A |
HP StorageWorks 1/8 G2 LTO-4 Ultrium 1760 SAS Tape Autoloader |
|
|
AK378A |
HP StorageWorks MSL2024 1 LTO-4 Ultrium 1760 SAS Drive Library |
|
|
AK379A |
HP StorageWorks MSL2024 0-drive, 24 Slot Tape Library |
|
|
AK380A |
HP StorageWorks MSL4048 2 LTO-4 Ultrium 1760 SAS Drive Library |
|
|
AK381A |
HP MSL2024 Ultr 920 SAS Tape Library |
|
|
AK382A |
HP StorageWorks MSL8096 2 LTO-4 Ultrium 1760 SAS Drive Library |
|
|
AP835A |
HP StorageWorks DAT 320 USB Tape Drive in 1U USB Rack Kit |
|
|
AU300A |
HP MSL8048 0-drive 48 Slot Tape Library |
|
|
DW085A |
HP StorageWorks Ultrium 448 SAS Internal Tape Drive |
|
|
EH847A |
HP StorageWorks Ultrium 920 SAS Internal Tape Drive |
|
|
EH860A |
HP StorageWorks LTO-4 Ultrium 1840 SAS Internal Tape Drive |
|
|
EH899A |
HP StorageWorks LTO-5 Ultrium 3280 Internal Tape Drive |
|
|
EH919A |
HP StorageWorks LTO-4 Ultrium 1760 SAS Internal Tape Drive |
|
風扇 |
|
|
|
|
407747-001 |
Fan - Hot-plug fan assembly, 60mm x 38mm |
|
導軌 |
|
|
|
|
AF092A |
HP 10642 G2 1200mm deep Shock Rack |
|
|
AF094A |
HP 10647 G2 1200mm deep Shock Rack |
|
線纜 |
|
|
|
|
142257-003 |
HP IEC320-C14 to C13 (10A/10ft/3.0m) PDU Cable |
|
|
417836-B21 |
Smart Array P400 battery attach cable kit - 61cm (24in) long |
|
其它 |
|
|
|
|
252663-B21 |
HP Modular Power Distribution Units (mPDU), High Volt Model, 40A (200-240 VAC) (WW) |
|
|
252663-B24 |
HP Modular Power Distribution Unit(mPDU), High Volt Model, 16A (200-240 VAC) (WW) |
|
|
252663-D71 |
HP Modular Power Distribution Units (mPDU), Low Volt Model, 24A (100-127 VAC) (NA, Japan) |
|
|
252663-D72 |
HP 24A High Voltage Modular Power Distribution Unit (North America, Japan) - 4.9 kVA Modular PDU, 24A |
|
|
252663-D73 |
HP Modular Power Distribution Units (Zero-U/1U Modular PDU) - 8.3 kVA Modular PDU, 40A (USA, Canada, Japan) |
|
|
337972-B21 |
HP Smart Array P600/256 BBWC Controller |
|
|
364430-B21 |
HP StorageWorks 50 Modular Smart Array |
|
|
381513-B21 |
HP Smart Array P800/512 BBWC Controller |
|
|
405132-B21 |
HP Smart Array P400/256MB Controller |
|
|
411064-B21 |
HP Smart Array P400/512MB Controller with BBWC |
|
|
411508-B21 |
HP Smart Array E200/128 BBWC Controller |
|
|
418408-B21 |
HP StorageWorks 60 Modular Smart Array |
|
|
418800-B21 |
HP StorageWorks 70 Modular Smart Array |
|
|
435129-B21 |
HP Smart Array E500/256MB Controller |
|
|
452148-B22 |
HP Insight Control suite, No Media 1-Server License including 1 year of 24x7 Technical Support and Updates |
|
|
452151-B21 |
HP Insight Rapid Deployment software No Media 1-Server License including 1 year of 24x7 Technical Support and Updates |
|
|
452180-B21 |
DL580 G5 SAS SFF 8-bay drive cage option |
|
|
453744-B21 |
DL580 G5 tower kit |
|
|
462830-B21 |
HP Smart Array P411/256 2-ports Ext PCIe x8 SAS Controller |
|
|
462832-B21 |
HP Smart Array P411/512 BBWC 2-ports Ext PCIe x8 SAS Controller |
|
|
462834-B21 |
HP Smart Array P212/256 1-ports Int/1-ports Ext PCIe x8 SAS Controller |
|
|
462862-B21 |
HP Smart Array P410/256 2-ports Int PCIe x8 SAS Controller |
|
|
462864-B21 |
HP Smart Array P410/512 BBWC 2-ports Int PCIe x8 SAS Controller |
|
|
487204-B21 |
HP Smart Array P812/1G FBWC 2-ports Int/4-ports Ext PCIe x8 SAS Controller |
|
|
487381-B21 |
HP ProLiant DL580 G5 highly serviceable rack chassis |
|
|
502550-B21 |
HP ProLiant DL580 G5 highly serviceable tower chassis |
|
|
512485-B21 |
HP iLO Advanced including 1yr 24x7 Technical Support and Updates Single Server License |
|
|
516471-B21 |
HP Smart Array Advanced Pack including 1yr 24x7 Technical Support and Updates Single Server License |
|
|
600278-B21 |
HP 160GB Single Level Cell PCIe ioDrive for ProLiant Servers |
|
|
600279-B21 |
HP 320GB Multi Level Cell PCIe ioDrive for ProLiant Servers |
|
|
600281-B21 |
HP 320GB Single Level Cell PCIe ioDrive Duo for ProLiant Servers |
|
|
600282-B21 |
HP 640GB Multi Level Cell PCIe ioDrive Duo for ProLiant Servers |
|
|
608447-B21 |
HP 2GB USB Flash Media Drive Key Kit |
|
|
AF001A |
10642 G2 (42U) Rack Cabinet - Pallet |
|
|
AF002A |
10642 G2 (42U) Rack Cabinet - Shock Pallet |
|
|
AF426A |
HP Rack Uninterruptible Power System R5500 (North America or Japan) |
|
|
AF504A |
HP monitored single Power Distribution Unit (PDU) S1324 (North America, Japan) - 3PH, 24A, 8.6 kVA |
|
|
AF506A |
HP Single Input 1 Phase 40A Monitored Power Distribution Unit (North America, Japan) |
|
|
AF616A |
HP Server Console 0x2x8 Port Analog Switch |
|
|
AF617A |
HP Server Console 0x2x16 Port Analog Switch |
|
|
AF618A |
HP 0x2x16 KVM Server Console Switch G2 with Virtual Media CAC Software |
|
|
AF619A |
HP 0x2x32 KVM Server Console Switch G2 with Virtual Media CAC Software |
|
|
AF620A |
HP 1x1Ex8 KVM IP Console Switch G2 with Virtual Media CAC Software |
|
|
AF621A |
HP 2x1Ex16 KVM IP Console Switch G2 with Virtual Media CAC Software |
|
|
AF622A |
HP 4x1Ex32 KVM IP Console Switch G2 with Virtual Media CAC Software |
|
|
AJ934A |
HP RDX500 Internal Removable Disk Backup System |
|
|
AJ940A |
HP D2600 Disk Enclosure |
|
|
AW577A |
HP StorageWorks RDX750 Internal Removable Disk Backup System |
|
|
DC172B |
HP USB 2-Button Optical scrolling mouse (Carbonite Black and Silver) - Has 1.8m (6.0 feet) long cable with USB connector |
|
|
DT528A#ABA |
HP Keyboard (USB) standard 2004 |
|
|
T9074BAE |
HP Insight Control including 1yr 24x7 Technical Support and Updates Electronic License |
|
|
T9082AAE |
HP Insight Control Server Deployment including 1yr 24x7 Support Electronic License |
|
|
TA850AAE |
HP iLO Advanced including 1yr 24x7 Technical Support and Updates Electronic License |
|
|
TC208A |
HP Insight Control for Linux Media Kit |
|
|
TC209A |
HP Insight Control for Linux including 1yr 24x7 Support Single Server License |
|
|
TC213AAE |
HP Insight Control for Linux including 1yr 24x7 Support Electronic License |
|
|
TC275A |
HP Insight Control including 1yr 24x7 Support ProLiant ML/DL/BL-bundle Tracking License |
|
|
TC278AAE |
HP Insight Control including 1yr 24x7 Support ProLiant ML/DL/BL-bundle Electronic License |
|
|
U4607E |
4-Hour On-site Service, 5-Day x 13-Hour Coverage, 3 Years, Electronic |
|
|
U4608E |
4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years, Electronic |
|
|
U4609E |
6-Hour Call to Repair, On-site Service, 7-Day x 24-Hour Coverage, 3 Years, Electronic |
|
|
U4617E |
Hardware Installation, Electronic |
|
|
U4618E |
Installation & Start-Up of a ProLiant server and Microsoft or Linux O/S per the Customer Description and/or Data Sheet. To be delivered on a scheduled basis 8am-5pm, M-F, excl. HP holidays, Electronic |
|
|
U4619E |
Onsite HW support, 8am-9pm, M-F, 4hr response and Microsoft O/S SW Tech support offsite, onsite at HP's discretion, 8am-9pm, M-F 2hr response time excl. HP holidays, Electronic |
|
|
U4620E |
Onsite HW support 24x7, 4hr response and Microsoft O/S SW Tech support offsite, onsite at HP's discretion, 24x7 2hr response time incl. HP holidays, Electronic |
|
|
U5683E |
Installation and Startup for Essentials Rapid Deployment Pack, Electronic |
|
|
U6316E |
Onsite HW support 24x7, 4hr response and SuSE O/S SW Tech support offsite, onsite at HP's discretion, 24x7 2hr response time incl. HP holidays, Electronic |
